4.5’x120″ Camry Golf Carpet + DIY Build Plan Below

Rated 5.00 out of 5 based on 2 customer ratings
(2 customer reviews)

$100.00$107.00

Camry Carpet is used by PGA Tour pros as is best emulates Tour level greens. 11 speed and true in every direction. You can even throw down chalk lines for practice!

– 54″ x 120″ Camry golf carpet roll

– Free DIY build plan below.

Indoor Putting Green DIY Build Plan
By CamryGolf

Indoor Putting Green DIY Build Plan – (Materials Needed, Slopes, Carpet, Application).  Other DIY applications using Camry Carpet: Entire Rooms, Flooring Concrete, Subfloors.



An indoor putting green could be extremely valuable and a lot of fun improving your stroke. It could be for you, or it could also be a practice area for your son/daughter. We at Camry see it as an investment. There’s no better feeling than putting at home while watching the game or the weather isn’t cooperating. An indoor putting green is not appreciated enough until it’s 100+ degrees outside or below 0 and freezing!

If you have some pretty basic tools lying around and are at least a little handy, you can do this no sweat. For reference, a 4×15′ green like the one below would cost ~$250 to build – carpet and all materials in!

Links to the exact items purchased to build this green are also be listed below.

2×4 framing , 2×4 horizontal beams

2×4 frame, 2×4 horizontal beams for support (typically 1.5′ – 2.5′ feet apart).

Topped off with 3/4” particle board for the base.

Particle board or Plywood works. 1/2″ or 3/4″ are ideal.

Drill holes using hole saw – 4 1/4″. Amazon Product Linkhttps://amzn.to/3vyLXaB

Apply carpet adhesive spread finely with the teeth pattern using a  1/16” trowel. Product Link:https://amzn.to/3x4pgsv
UNROLL camry carpet on for an even application.

Slit a small ‘X’ in the carpet with an exacto-knife where the Holes are and slide in Regulation cups for a flush Look.

Regulation Cups should be bought 4″ deep. Product Linkhttps://camrygolf.com/product/4-regulation-size-putting-cup-1-piece/



To Add break ; Use Our HEAVY DUTY levers! (See Photo Below, bottom left corner is the lever. Works like a Charm!)

Our Haavy Duty Putting Green Levers are the easiest way to add undulation to make right to left, or even slower uphill putts. https://camrygolf.com/product/heavy-duty-golf-putting-green-levers-for-slope-break/

A Couple of Notes:

  • Build it where you want to use it if you can.  It will be awkward to move.
  • You can adjust this build to whatever size you want to make it.  The only tricky part may be making sure the underlayment is perfectly flush if you have to use more than 1 piece.  We suggest planning 4′ width increment greens since the particle board comes at 4′ standard from local shops.
  •  Camry carpet is the best roll, and also shaves off about $100 vs the Big Moss artifical turf. Simply choose out the sizing you need from our Shop, or email us at camrygolfgreens@outlook,com for custom sizing. Prices are going to vary and we always do our best to get the best price.
  • Slit an X in the carpet! people try to make the mistake of cutting out a perfect circle- thats a NO-NO. This will save you a lot of trouble and it will no doubt be cleaner than you or I can do it.  Use an exacto knife and make the x just large enough for the cups to slide in flush with the carept wedge in between the cup and wood.
  • Use tarp to cover if you are placing it outside.
  • With these dimensions, you can comfortably practice up to a 15ft putt and add break to it if you want. The material rolls at 11 speed, but you can use the furniture levels on one end to hit uphill putts rolling at 7-10 speed(ITS AMAZING).
Finished Product. 4′ x 15′ for $200 All-In! ?

Links to the products used:

1/16″ Trowel – Amazon https://amzn.to/3x4pgsv

Hole Saw – Amazon https://amzn.to/3vyLXaB

Furniture Levelers  – Amazon  https://amzn.to/3kT7S7s

Regulation 4″ Deep Cups  – https://camrygolf.com/product/4-regulation-size-putting-cup-1-piece/

Camry Trunk Carpet Putting Surface- https://camrygolf.com/product/4-5-x-15-roll/

Roberts 6700 glue  –  https://www.homedepot.com/p/ROBERTS-1-Gal-Indoor-Outdoor-Carpet-and-Artificial-Turf-Adhesive-6700-1/100117949







Size

4.5'x10', 4.5'x12'
